AcBel R21S7651A-G 650W 80+ Gold Redundant Power Supply NEW
- Safety according to EN 60950-1 :2006/UL 60950-1 2nd Edition
- PSMC accuracy within 5% (Current, Voltage, Temp, Power)
- Embedded Buzzer Alarm with reset port function.
- Energy Star compliances for Computer Server 2.0
- Power module efficiency: 80plus Gold certified.
- LED indicators for power status (Green/Amber).
- Low Acoustic design by Digital Fan control.
- PSON, PG/PWOK, 5MBAlert signaling.
- Designed for Intel Haswell platform.
- High Voltage 240VDC compatible.
- PMBus 1.2 compliant.
( 1 Pcs in Stock)
Note: Image above may show a varied configuration or optional part. Please refer to parts list for standard parts included.
| SKU | 09000042-R21S7651A-G | ||||||||||||||||||||||||||||||||
| Details | Input Voltage Range:
90-264Vac Input Frequency Range:
47/63Hz Leakage Current:
< 3.5mA when tested at 240Vac AC Input Current:
9.5A@115Vac / 4.5A@230Vac PFC (Harmonic):
Meet EN61000-3-2 EMI/RFI:
CISPR 22 Class A Output Power:
650W Efficiency:
80%@20%; 85%@50%; 80%@100% load. OVP:
+5V: <6.5V; +3.3V: <4.5V; +12V: <15.0V OCP:
110% - 150%, peak current sustain 1OSee. OTP:
Auto Recover, if temp returns within Spec. SCP:
Latch off all main outputs reset by cycling on/off control or AC power Hold-up Time:
12mS@100% load Dimensions:
L260 x W101 x H83.5 (mm) MTBF:
100,000 hours min at full load, +40·e Output Rise Time:
5 - 70mS Power Factor:
0.90 typical load Operating Temperature:
o·e - +50·e Storage Temperature:
-40·e - +70·e
|
|
|
Note: Image above may show a varied configuration or optional part. Please refer to parts list for standard parts included.
